FLEXIBLE HIGH-SPEED BILATERAL PRODUCTION LINE

each GF seriesdouble edging machine has a unique double opening and closing function, Coarsegrinding and polishing are divided into two sections, after the glass is conveyed.segmented edging can be carried out to process different sizes of glass, the efficiencyis twice that of the traditional high-speed edging machine, saving 50% of electricity consumption.

also supports the cameracode scanning function,intelligently identifies large and small glasses, and can automaticallyiconnect loading and unloading tables, glass sorting machines, washing machines and other:isupporting equipment The whole process line is convenient,efficient safe and inteligent



Specifications


ModelGY1620GY2020GY2520GY3020GY4020
Min size280mm280mm280mm280mm180mm
Max size1600mm2000mm2500mm30000mm4200mm
Thickness3-25mm3-25mm3-25mm3-25mm3-25mm
Transmission speed0.5-16m/min0.5-20m/min0.5-20m/min0.5-20m/min0.5-20m/min
Diagonal error+0.5mm/m+0.5mm/m+0.5mm/m+0.5mm/m+0.5mm/m
Total power47.4KW47.4kW47.4KW47.4KW47.4KW
Dimension4690x4000x2000mm4690x4400x2000mm 4690x4900x2000mm4690x5400x2000mm4690x6600x2000mm
Weight7300kg8200kg9000kg10000kg11000kg
